Whirlpool Duet W10151592A Uživatelský manuál

ELECTRONIC ELECTRIC DRYERUse & Care GuideFor questions about features, operation/performance, parts, accessories or service, call: 1-800-253-1301o

102. Remove neutral ground wire from external ground conductor screw. Connect neutral ground wire and the neutral wire (white or center wire) of power

113. Connect ground wire (green or bare) of direct wire cable to external ground conductor screw. Tighten screw.4. Place the hooked ends of the other

12When connecting to the terminal block, place the hooked end of the wire under the screw of the terminal block (hook facing right), squeeze hooked en

13Venting RequirementsWARNING: To reduce the risk of fire, this dryer MUST BE EXHAUSTED OUTDOORS.IMPORTANT: Observe all governing codes and ordinances

14 An exhaust hood should cap the vent to keep rodents and insects from entering the home. Exhaust hood must be at least 12" (30.5 cm) from the

15 Over-the-Top Installation: Part Number 4396028 Periscope Installation (For use with dryer vent to wall vent mismatch):Part Number 4396037 - 0&quo

162. Firmly grasp the body of the dryer (not the console panel). Gently lay the dryer on the cardboard. See illustration. 3. Examine the leveling l

17DRYER USEStarting Your DryerWARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS before

18 Press and hold START button until dryer starts (about 1 second).Once an Automatic cycle has started, the WRINKLE SHIELD™ feature and cycle signals

19 Avoid drying heavy work clothes with lighter fabrics. This could cause overdrying of lighter fabrics, leading to increased shrinking or wrinkling.

2TABLE OF CONTENTSDRYER SAFETY...2INSTALLATION INSTRUCTIONS...

20Damp DryUse this cycle to dry items to a damp level using Low heat. Damp dry items such as jeans (to avoid stiffness) or cotton clothing (to make ir

21 Stop at any time by pressing the WRINKLE SHIELD™ feature or opening the dryer door. For the Casual Cycle, the WRINKLE SHIELD™ feature is preset t

22To use the drying rackDo not remove the lint screen.1. Open dryer door.2. Place drying rack inside dryer drum, positioning the back wire on the ledg

23IMPORTANT: Do not run the dryer with the lint screen loose, damaged, blocked, or missing. Doing so can cause overheating and damage to both the dry

24 TROUBLESHOOTING First try the solutions suggested here or visit our website and reference FAQs (Frequently Asked Questions) to possibly avoid the c

25 Is the exhaust vent diameter the correct size? Use 4" (10.2 cm) diameter vent material. Is the dryer located in a room with temperature belo

26ASSISTANCE OR SERVICEBefore calling for assistance or service, please check “Troubleshooting.” It may save you the cost of a service call. If you st

27Notes

WHIRLPOOL CORPORATION MAJOR APPLIANCE WARRANTYONE YEAR LIMITED WARRANTYFor one year from the date of purchase, when this major appliance is operated a

3INSTALLATION INSTRUCTIONSTools and PartsGather the required tools and parts before starting installation. Read and follow the instructions provided w

4OptionsPedestalAre you placing the dryer on a pedestal? You have the option of purchasing pedestals of different heights separately for this dryer. Y

5Do not operate your dryer at temperatures below 45ºF (7ºC). At lower temperatures, the dryer might not shut off at the end of an automatic cycle. Thi

6Recommended installation spacing for cabinet installation For cabinet installation, with a door, minimum ventilation openings in the top of the cabi

7 To supply the required 3 or 4 wire, single phase, 120/240 volt, 60 Hz., AC only electrical supply (or 3 or 4 wire, 120/208 volt electrical supply,

8Electrical Connection1. Disconnect power.2. Remove the hold-down screw and terminal block cover. 3. Install strain relief.Style 1: Power supply cord

9Style 2: Direct wire strain relief Unscrew the removable conduit connector and any screws from a ³⁄₄" (1.9 cm) UL listed strain relief (UL mark
